- Size: 2000*2300*2650
- Place of Origin: ShanDong
- Brand Name: hongxiang
- Model Number: ZK650-1
- Weight: 3500.000 kg
HXZK650-1 | ||||
Table surface
| Size of table surface
| 700*550 | ||
Max.loading
| 600 | |||
T slot size
| 5-18*100 | |||
Travel
| X axis | 600 | ||
Y axis
| 500 | |||
Z axis
| 400 | |||
Spindle nose to table center
| 最大 Max
| 510 | ||
最小 Min
| 110 | |||
spindle
| Taper(7:24)
| BT30 | ||
Speed range
| 0 ～8000 | |||
Max output torque
| 35 | |||
Motor power
| 5.5 | |||
Spindle drive | 同步带 | |||
tool | Type of shank | BT30 | ||
Rivet type | BT30- Ⅰ | |||
feed
|
Rapid speed
| X 轴 X axis
| 13 | |
Y 轴 Y axis
| 13 | |||
|
| 13 | |||
feed rate | 0-8000 | |||
Three axis drive motor power | 2/1.5/2.3 | |||
Positioning accuracy |
| JIS 标准 | GB 标准
| |
X 轴 X axis | ±0.02 | 0.03 | ||
Y 轴 Y axis | ±0.02 | 0.03 | ||
Z 轴 Z axis | ±0.02 | 0.03 | ||
Repeated positioning accuracy(mm) | X 轴 X axis | ±1.5 | 0.02 | |
Y 轴 Y axis | ±1.5 | 0.02 | ||
Z 轴 Z axis | ±1.5 | 0.02 | ||
weight of machine | 3500 | |||
Total electric capacity | 7 | |||
overall dimension of machine | 2000 ×2300×2650 | |||
- Size: 2000*2300*2650
- Place of Origin: ShanDong
- Brand Name: hongxiang
- Model Number: ZK650-1
- Weight: 3500.000 kg
